Best practice with PMMA

PMMA is a wonderful material, sturdy and durable. But as with all plastics, it could be prone to scratches. Do not play with jewellry or wristwatch on. I've conducted tests on mine, it can easily withstand a lot of abuse, even some punches is the defeat is too crushing, but it could shatter upon impact in case of fall on the ground. Keep the impacts virtuals.

Do NOT use alcohol/solvent based product to clean it.

COMPATIBILITY & TECHNICAL QUESTIONS

Which sticks is the case compatible with ?

Due to the height of the case, only Sanwa sticks (JLF and JLX series) are compatible.

Which buttons are compatible?

The case supports:

• 30 mm main buttons (Sanwa, Seimitsu, Qanba, etc.)
• 24 mm auxiliary buttons for Start/Select/Back/etc.

It’s recommended to use screw-in buttons.

Which PCBs are compatible?

The provided board tray is compatible with any usb board using the Brook form factor. I recommend using either a Brook Gen5 series board or a GP2040 Advanced Breakout board

Is the case compatible with PS4 / PS5 / Xbox?

It depends on the PCB you install, not the case itself. For PS5 and Xbox Series, an additionnal dongle may be required.

Is the stick plug-and-play?

• Case-only models: No, you need to install your own PCB, wiring, and joystick.
• Fully wired models (e.g., cat-shaped prototype): Yes, plug-and-play via USB, depending on PCB compatibility with your system.

What is the PMMA thickness?

PMMA panel thickness: 3 mm, doubled on top and bottom

Is the wrist rest removable?

No.

The bent PMMA wrist rest is part of the main structure.

What is the total weight?

Approximate weight: 1,7 kg (depending on components installed.)

Are the button holes compatible with screw-in AND snap-in buttons?

Yes.

Both snap-in and screw-in buttons fit (30 mm / 24 mm), although you will have a sturdier assembly with screw-ins.

Is there enough space for a silent JLF, octogate, or spring mod?

Yes.

The internal height supports:

• Silent JLF mods
• Octogates
• Springs and lever mods
• Standard balltop or battop

Can I install a Korean joystick (Crown, etc.)?

No.

The mounting pattern and internal depth are not compatible.

Is the USB cable detachable?

Yes.

All builds use a standard external USB cable.

Can the case be opened easily for modding?

Yes.

All parts are screwed together (no glue), accessible from top or bottom.

Which OLED module fits the cutout?

The window fits a 1.3" OLED module, typical SSD1306 footprint.

Internal height?

Internal height clearance: 37 mm.

Can I install an SOCD cleaner?

Yes.

Any compact SOCD-cleaner PCB fits inside.

Can I install an optical joystick (Flash1, Spark CE)?

Yes, as long as it uses the Sanwa JLF format.

ASSEMBLY QUESTIONS

How do I install the joystick?

The JLF mounts from the inside using M4 screws.

Access is via the top panel.

Does the case open from the top or bottom?

You can open it either way, although once installed it’s recommended to open it from the bottom.

Are the threaded inserts already installed?

Yes.

All threaded inserts are pre-installed in the 3d printed parts.

Is there a wiring tutorial?

I myself used this wonderful one from ANDYUKFM https://drive.google.com/file/d/1Ho5ItRj8jMYTG4tVbq0kyc-aFqbbF-iD/view

Are cables included?

Only for fully-wired models.

Case-only versions include no wiring.

How do I wire the leverless directional buttons?

The extra directional buttons map to:

• UP / DOWN / LEFT / RIGHT
• with shared GND

Exact pin mapping depends on your PCB.

Is there room for a Brook board + USB daughterboard?

Yes, but you will have to find a way to secure it.

Will screw-in buttons hit the bottom panel?

No, but with standard connectors it will be a tight fit, it’s recommended to bend them.

Is it possible to add internal weights?

Yes.

Thin steel plates or adhesive weights can be added. Be careful of buttons location though.

SHIPPING QUESTIONS

How much is shipping?

14€ for France, 22€ for European countries.

Overseas buyers, please ask for a quote before purchase.

The buyer pays shipping + any import taxes.

Do you ship to the US / Canada / UK?

Yes, worldwide shipping is available.

Which carriers do you use?

Primarily:

• Colissimo
• UPS
• Mondial Relay (EU only)

Is insurance included?

Available on request (added cost).

How is the stick packaged?

• Double protective layer
• Bubble wrap
• Rigid cardboard
• Reinforced edges

Can I return the product?

Yes, within 14 days (prototype units must be returned in the same condition).

Buyer covers return shipping.

Shipping delay?

Units are already built.

Ships within XX days after payment.

PAYMENT QUESTIONS

Which payment methods do you accept?

Credit/debit card via SumUp.

Do you accept PayPal?

Yes, on request.

Can I get an invoice?

Yes, sent by email.

Is VAT included?

No.

VAT not applicable — French micro-entreprise (Art. 293B CGI).

QUALITY QUESTIONS

Some buttons feel tight. What should I do?

Laser-cut holes have tight tolerance.

Press firmly or rotate slightly during insertion.

There are minor marks on the plexi. Why?

Prototypes may show small surface marks from bending or assembly.

A 3d printed part cracked. Can you replace it?

Yes — replacement parts can be printed on request (quote required).

CUSTOMIZATION QUESTIONS

Can you install different buttons?

Yes, on request (price may vary).

Can you install a silent joystick?

Yes - compatible with silent Sanwa JLF.

Do you offer full wiring service?

Yes - See options on the shop.

Can you add artwork under the plexi?

• Transparent models: yes.
• Opaque PMMA models: no.

Do you offer different colors?

Not for the prototype batch.

Custom builds possible on request.

CAT-SHAPED MODEL QUESTIONS

Is the cat shape stable while playing?

Yes, the frame is rigid and stable on a flat surface.

Is it comfortable for long sessions?

It has a compact resting area, but remains comfortable for most players.

Will the cat model be reproduced?

Yes, on demand, please reach out for a quote.

Can you make another animal shape?

Possible — quote required depending on complexity.

FULL WIRING SERVICE QUESTIONS

What is included in full wiring?

• PCB installation ( a GP2040 Advanced Breakout Board with USB passthrough)
• JLF installation
• Full button wiring (30 mm / 24 mm)
• USB output
• Functional testing
